The Current Role of Laser Therapy in the Management of Diabetic Retinopathy

Laser continues to play an important role.

By: Sam Mansour, MD, David J. Browning, MD
Retinal Physician October 1, 2021 Vol 18, Issue October 2021 Page(s): 32-34, 41

Related

Over the past 2 decades, new approaches in pharmacotherapeutic management of diabetic retinopathy (DR) and diabetic macular edema (DME) have overshadowed developments in laser therapy for these conditions. Historically, the effectiveness of laser therapy for managing DR has been proven in several major clinical trials.1-5 However, conventional continuous wave (CW) laser is destructive to retinal cells and can result in scotomas.4,6-9 In addition, CW laser can worsen night vision and delay light-to-dark adaptation.10-12 Indirect macular changes attributable to PRP have also been reported.13-15 As such, there has been a decline in the use of laser therapy in DR and DME management by clinicians.16,17

LASER MODALITIES

In the late 1980s, clinicians began to investigate the use of lower laser power to treat DME. The Early Treatment of Diabetic Retinopathy Study (ETDRS) demonstrated the effectiveness of a “modified-ETDRS” pattern of less intense burns (Figure 1).3,4 A change in the microaneurysm color was not required for direct focal treatment and for grid treatment, the burn intensity was to be “barely visible.5 The “mild macular grid photocoagulation” varied from the ETDRS pattern of grid treatment in that the intensity was “barely visible” and also that the area of treatment was to both thickened and nonthickened retina within the macula.18,19

Figure 1. Fundus color (A), fluorescein angiography (B), and optical coherence tomography scan (C) of left eye 6 months following modified ETDRS sectoral grid laser application for diabetic macular edema. Focal, outer retinal pigmentary disturbances (arrows) are noted on all 3 imaging modalities.
Figure 1. Fundus color (A), fluorescein angiography (B), and optical coherence tomography scan (C) of left eye 6 months following modified ETDRS sectoral grid laser application for diabetic macular edema. Focal, outer retinal pigmentary disturbances (arrows) are noted on all 3 imaging modalities.

More recently, newer modes of laser retinal therapy, best termed low-intensity photo stimulation (LIPS), involve grid type application of nonphotocoagulative laser spots to “photostimulate” outer retinal tissues, primarily the retinal pigment epithelium (RPE), to either increase production of metabolites that inhibit neovascularization and reduce vascular permeability activity or to downregulate production of mediators that increase vascular permeability and neovascularization (Figure 2).20-27 To qualify as LIPS, a laser treatment session must not result in any detectable outer retinal or RPE damage on current imaging modalities such as fundus photography, angiography, autofluorescence, or optical coherence tomography. With this type of “subthreshold” laser, many of the benefits of CW lasers are theoretically obtained without the adverse side effects. Several laser manufacturers offer LIPS lasers systems, which include Micropulse and Endpoint Management (Iridex), Smartpulse (Lumenis), Easyret in subliminal mode (Quantel Medical), Navilas Microsecond Pulse (OD-OS), 2RT (Ellex), SP-Mode (Lightmed), and LPM (Nidek), all of which can be safely applied near the fovea without visible damage when used according to published safety protocols. There have been several small, uncontrolled studies that have shown the benefits of LIPS lasers in treating DME either alone or in combination with pharmacotherapy, yielding results comparable to those obtained with conventional laser but with no tissue damage or scotomas.18,19,28-44

Figure 2. Optical coherence tomography images of a right eye of a patient with chronic diabetic macular edema before (A) and after (B) low-intensity photo stimulation (Micropulse; Iridex) grid application. There was no evidence of outer retinal structural changes seen 4 months following the procedure.
Figure 2. Optical coherence tomography images of a right eye of a patient with chronic diabetic macular edema before (A) and after (B) low-intensity photo stimulation (Micropulse; Iridex) grid application. There was no evidence of outer retinal structural changes seen 4 months following the procedure.

LASER USE IN PROLIFERATIVE DIABETIC RETINOPATHY

Treatment of neovascularization by panretinal laser photocoagulation (PRP) remains unchanged since the Diabetic Retinopathy Study (DRS) proved its efficacy in proliferative diabetic retinopathy (PDR). Recently, attempts to integrate pharmacotherapy to minimize the visual side effects of PRP have been shown to work in adherent patients. Several studies have demonstrated improved visual outcomes of intravitreal anti-VEGF injections vs PRP.45-47 In patients with PDR-related vitreous hemorrhage (VH), there was no statistically significant difference in visual acuity over 24 weeks following initial treatment with intravitreous aflibercept vs vitrectomy with PRP integration.48 The use of targeted PRP to ischemic retina as delineated on widefield fluorescein angiography has not been demonstrated to be superior to standard PRP in preventing neovascularization.49 Likewise, with limited study, there is no advantage of LIPS laser compared to conventional PRP for PDR.42 Panretinal laser photocoagulation for PDR is superior to pharmacotherapy when either medical and financial resources are limited or patient adherence is poor.47,50,51

LASER USE IN DIABETIC MACULAR EDEMA

The management of nonproliferative diabetic retinopathy (NPDR) and DME continues to evolve with regards to laser modalities and integration of pharmacotherapeutics. The initial clinical trial of the DRCR Retina Network published in 2007 illustrates the modest evolution of laser techniques for management of DME.52,53 In cases with mild, center-involving DME, focal or grid laser treatment was shown in protocol V of the DRCR Network to be equivalent to observation or anti-VEGF therapy.54,55 As a result, a “watchful wait” approach to managing patients with mild DME and best-corrected visual acuity of 20/25 or better is supported. Attempts to lessen the burden of anti-VEGF injections in the setting of DME by integrating peripheral PRP have had mixed results.49,56,57 Data from the DAVE trial examining widefield, targeted PRP in conjunction with intravitreal ranibizumab for DME have demonstrated no significant reduction in the frequency of prn injections.49,56

COMBINATION LASER AND PHARMACOTHERAPY

To date, there have been few clinical trials examining whether integration of laser therapy, either conventional, targeted, or in LIPS mode, with pharmacotherapy can result in a reduced treatment burden for the patient while achieving optimal clinical efficacy. The results of some clinical trials have demonstrated that supplementing pharmacotherapy with laser therapy, both as focal and grid application for macular edema and as PRP application for proliferative disease may provide a more durable response.58-64 In PDR, some reports have suggested that combination treatment with anti-VEGF and PRP may reduce treatment burden compared to anti-VEGF monotherapy.62,65-69 Other studies have shown no significant benefit of the combination treatments.55,70-72 Data from protocol S of the DRCR Retina Network demonstrated that both PRP and intravitreal ranibizumab were similar in the prevention of severe visual loss and other complications in PDR, suggesting that patient-specific factors such as compliance and financial impact be considered primarily in management decisions.46,73

Protocol I of the DRCR Retina Network demonstrated no short-term benefit in combining prompt macular laser with anti-VEGF therapy for center-involved DME.74 However, patients who were treated with deferred laser therapy achieved the best outcome in terms of 2-year visual improvement. Protocol T of the DRCR Network was a comparative effectiveness trial utilizing bevacizumab, ranibizumab, or aflibercept.58 As part of the protocol, laser treatment was mandated for persistent centrally involved macular edema at the 24 week follow-up examination following monthly initial treatment by 1 of the 3 agents. At the 1 year follow-up examination, 50% of eyes in the study had received laser treatment because of persistent macular edema. There was a slightly higher percentage of patients receiving laser in the bevacizumab group and a lower percentage in the aflibercept treated group compared to the 2 other agents. In addition, deferred macular laser was still required in more than 30% of study eyes with center-involved DME receiving ranibizumab in the RISE and RIDE studies.74

These studies emphasize the beneficial influence of specific targeted focal and grid laser treatment in eyes not responding initially to anti-VEGF agents alone. In addition, the same trial demonstrated that regardless of the anti-VEGF agent used, there was nearly a 50% reduction in the frequency of needed injections in the second year.75

Results of clinical trials examining integration of LIPS laser therapy and pharmacotherapeutics in DME have yielded mixed results.76-79 Many studies have demonstrated a synergistic effect. Other studies have shown equivalency of effect between anti-VEGF therapy and LIPS particularly in early, mild DME.80 Recently, some potential benefit of LIPS laser in DME patients with subretinal fluid has been demonstrated in a retrospective series, while other studies have shown no added benefit of LIPS to intravitreal anti-VEGF agents.81-83

The result of combining laser therapy with intravitreal corticosteroids have also been inconsistent in terms of both visual acuity stabilization or improvement, and reduction in overall treatment burden.72,76,77,84-86 Concerns regarding elevated intraocular pressure and acceleration of cataract formation associated with the use of corticosteroids limit their use in DME.77,87 However a few studies have demonstrated potential benefit of intravitreal corticosteroids in conjunction with laser therapy in DME.76,78,79

A methodologically sound, adequately sized trial to determine supplemental laser treatment might reduce anti-VEGF treatment burden has not yet been done. Despite the lack of high-quality evidence, guidelines for the integration of laser and pharmacotherapy in DME management have been proposed.84-86,88

ADVANCES IN LASER THERAPY FOR DR

Another new development in retinal laser therapy for DR is a fundus camera-based photocoagulation system that is integrated with retinal eye-tracking technology (Navilas; OD-OS).89-91 This technique allows the ophthalmologist to take an image of the retina of a patient with DR or DME, digitally encircle the areas requiring treatment, and have the device automatically deliver the laser spots to the specified areas. Higher accuracy of laser delivery compared with conventional, manually operated lasers can be achieved.89-92 In managing patients with proliferative disease, this system is able to deliver a “navigated” pattern PRP that is selectively applied to areas of ischemia identified by widefield fluorescein angiography. Fewer, more uniform laser burns are delivered in shorter time and with less discomfort and potentially less overall retinal tissue damage.93,94 Recent, uncontrolled studies have demonstrated that when used in combination with pharmacotherapy, the patients receiving Navilas-guided focal laser required fewer injections of anti-VEGF agents than would otherwise have been required to maintain remission of the macular edema.95,96

A novel use of lasers in DR involves the use of pulsed mode, near-infrared (NIR) lasers to activate the release of liposomes within an intravitreal injected, biodegradable capsule.97,98 The goal of this on-demand, dose-controllable drug delivery system is to reduce the frequency of intravitreal injections.

CONCLUSION

For clinicians, therapy for managing DR and DME that arrests neovascularization, quickly eliminates macular edema, has few side effects and long duration, and is low cost remains elusive. It is hoped that with additional, well structured, large, controlled, prospective clinical trials examining combination therapies that this ideal will be achieved. Further studies to explore potential benefits of combination treatment are planned, perhaps involving widefield imaging-guided peripheral laser to ischemic retina and a subthreshold technique. For now, use of laser therapy for managing diabetes-related retinal disease will continue to play a role. Situations that preclude the use of pharmacotherapy in DME and DR, such as unreliable patient visit compliance, pregnancy, or nonresponse to anti-VEGF, can be managed by laser therapy. Large, prospective comparative trials are needed to determine if the newer subthreshold and navigated laser techniques are superior to conventional laser methods. RP

Sam E. Mansour, MD, is the medical director at Virginia Retina Center in Warrenton, Virginia, and a clinical professor of ophthalmology at The George Washington University in Washington, DC. He reports grants from Alimera Sciences, Inc.; consultancy to, lectures for, and grants from Iridex; and research for Genentech, Allergan, Alcon, Clearside Biomedical, Chengdu Kanghong Biotechnology, and Mylan GmbH. David J. Browning, MD, is a retina specialist with Charlotte Eye, Ear, Nose, and Throat Associates in Charlotte, North Carolina. Dr. Browning reports grants from DRCR Retina Network. Reach Dr. Mansour at sm@virginiaretina.com. Editor’s note: Listen to discussion of this article on the Retina Podcast at retinapodcast.com .

REFERENCES

  1. Four risk factors for severe visual loss in diabetic retinopathy. The third report from the Diabetic Retinopathy Study. The Diabetic Retinopathy Study Research Group. Arch Ophthalmol. 1979;97(4):654-655. doi:10.1001/archopht.1979.01020010310003
  2. Photocoagulation treatment of proliferative diabetic retinopathy. Clinical application of Diabetic Retinopathy Study (DRS) findings, DRS Report Number 8. The Diabetic Retinopathy Study Research Group. Ophthalmology. 1981;88(7):583-600.
  3. Photocoagulation for diabetic macular edema. Early Treatment Diabetic Retinopathy Study report number 1. Early Treatment Diabetic Retinopathy Study research group. Arch Ophthalmol. 1985;103(12):1796-1806.
  4. Striph GG, Hart WM Jr, Olk RJ. Modified grid laser photocoagulation for diabetic macular edema. The effect on the central visual field. Ophthalmology. 1988;95(12):1673-1679. doi:10.1016/s0161-6420(88)32957-x
  5. Early photocoagulation for diabetic retinopathy. ETDRS report number 9. Early Treatment Diabetic Retinopathy Study Research Group. Ophthalmology. 1991;98(5 Suppl):766-785.
  6. Sims LM, Stoessel K, Thompson JT, Hirsch J. Assessment of visual-field changes before and after focal photocoagulation for clinically significant diabetic macular edema. Ophthalmologica. 1990;200(3):133-141. doi:10.1159/000310094
  7. Rohrschneider K, Bültmann S, Glück R, Kruse FE, Fendrich T, Völcker HE. Scanning laser ophthalmoscope fundus perimetry before and after laser photocoagulation for clinically significant diabetic macular edema. Am J Ophthalmol. 2000;129(1):27-32. doi:10.1016/s0002-9394(99)00270-6
  8. Lee HJ, Kang TS, Kwak BS, Jo YJ, Kim JY. Long-term effect of panretinal photocoagulation on spectral domain optical coherence tomography measurements in diabetic retinopathy. Curr Eye Res. 2017;42(8):1169-1173. doi:10.1080/02713683.2017.1280510
  9. Baptista PM, Marta AA, Heitor J, et al. Long-term visual function effects of pan-retinal photocoagulation in diabetic retinopathy and its impact in real life. Diabetes Metab Syndr Obes. 2021;14:1281-1293. Published 2021 Mar 19. doi:10.2147/DMSO.S301747
  10. Fong DS, Girach A, Boney A. Visual side effects of successful scatter laser photocoagulation surgery for proliferative diabetic retinopathy: a literature review. Retina. 2007;27(7):816-824. doi:10.1097/IAE.0b013e318042d32c
  11. Russell PW, Sekuler R, Fetkenhour C. Visual function after pan-retinal photocoagulation: a survey. Diabetes Care. 1985;8(1):57-63. doi:10.2337/diacare.8.1.57
  12. Seiberth V, Alexandridis E, Feng W. Function of the diabetic retina after panretinal argon laser coagulation. Graefes Arch Clin Exp Ophthalmol. 1987;225(6):385-390. doi:10.1007/BF02334163
  13. Doğan M, Kutluksaman B. Macular pigment optical density after panretinal photocoagulation. Clin Exp Optom. 2021;104(2):187-193. doi:10.1111/cxo.13126
  14. Sabaner MC, Dogan M, Akdogan M, Şimşek M. Panretinal laser photocoagulation decreases large foveal avascular zone area in non-proliferative diabetic retinopathy: A prospective OCTA study. Photodiagnosis Photodyn Ther. 2021;34:102298. doi:10.1016/j.pdpdt.2021.102298
  15. Diabetic Retinopathy Clinical Research Network, Brucker AJ, Qin H, et al. Observational study of the development of diabetic macular edema following panretinal (scatter) photocoagulation given in 1 or 4 sittings. Arch Ophthalmol. 2009;127(2):132-140. doi:10.1001/archophthalmol.2008.565
  16. Jusufbegovic D, Mugavin MO, Schaal S. Evolution of controlling diabetic retinopathy: changing trends in the management of diabetic macular edema at a single institution over the past decade. Retina. 2015;35(5):929-934. doi:10.1097/IAE.0000000000000438
  17. Song SJ, Han K, Choi KS, et al. Trends in diabetic retinopathy and related medical practices among type 2 diabetes patients: Results from the National Insurance Service Survey 2006-2013. J Diabetes Investig. 2018;9(1):173-178. doi:10.1111/jdi.12655
  18. Akduman L, Olk RJ. Subthreshold (invisible) modified grid diode laser photocoagulation in diffuse diabetic macular edema (DDME). Ophthalmic Surg Lasers. 1999;30(9):706-714.
  19. Friberg TR. Subthreshold (invisible) modified grid diode laser photocoagulation and diffuse diabetic macular edema (DDME). Ophthalmic Surg Lasers. 1999;30(9):705.
  20. Flaxel C, Bradle J, Acott T, Samples JR. Retinal pigment epithelium produces matrix metalloproteinases after laser treatment. Retina. 2007;27(5):629-634. doi:10.1097/01.iae.0000249561.02567.fd
  21. Gao X, Xing D. Molecular mechanisms of cell proliferation induced by low power laser irradiation. J Biomed Sci. 2009;16(1):4. Published 2009 Jan 12. doi:10.1186/1423-0127-16-4
  22. Hattenbach LO, Beck KF, Pfeilschifter J, Koch F, Ohrloff C, Schacke W. Pigment-epithelium-derived factor is upregulated in photocoagulated human retinal pigment epithelial cells. Ophthalmic Res. 2005;37(6):341-346. doi:10.1159/000088263
  23. Iwami H, Pruessner J, Shiraki K, Brinkmann R, Miura Y. Protective effect of a laser-induced sub-lethal temperature rise on RPE cells from oxidative stress. Exp Eye Res. 2014;124:37-47. doi:10.1016/j.exer.2014.04.014
  24. Kregel KC. Heat shock proteins: modifying factors in physiological stress responses and acquired thermotolerance. J Appl Physiol (1985). 2002;92(5):2177-2186. doi:10.1152/japplphysiol.01267.2001
  25. Miura Y, Treumer F, Klettner A, et al. VEGF and PEDF secretions over time following various laser irradiations on an RPE organ culture. Invest Ophthalmol Vis Sci. 2010;51(5):469.
  26. Sramek C, Mackanos M, Spitler R, et al. Non-damaging retinal phototherapy: dynamic range of heat shock protein expression. Invest Ophthalmol Vis Sci. 2011;52(3):1780-1787. Published 2011 Mar 28. doi:10.1167/iovs.10-5917
  27. Vujosevic S, Toma C, Villani E, et al. Subthreshold Micropulse Laser in Diabetic Macular Edema: 1-Year Improvement in OCT/OCT-Angiography Biomarkers. Transl Vis Sci Technol. 2020;9(10):31. Published 2020 Sep 30. doi:10.1167/tvst.9.10.31
  28. Friberg TR. Infrared micropulsed laser treatment for diabetic macular edema--subthreshold versus threshold lesions. Semin Ophthalmol. 2001;16(1):19-24. doi:10.1076/soph.16.1.19.4217
  29. Dorin G. Subthreshold and micropulse diode laser photocoagulation. Semin Ophthalmol. 2003;18(3):147-153. doi:10.1076/soph.18.3.147.29812
  30. Laursen ML, Moeller F, Sander B, Sjoelie AK. Subthreshold micropulse diode laser treatment in diabetic macular oedema. Br J Ophthalmol. 2004;88(9):1173-1179. doi:10.1136/bjo.2003.040949
  31. Luttrull JK, Musch DC, Mainster MA. Subthreshold diode micropulse photocoagulation for the treatment of clinically significant diabetic macular oedema. Br J Ophthalmol. 2005;89(1):74-80. doi:10.1136/bjo.2004.051540
  32. Sivaprasad S, Sandhu R, Tandon A, Sayed-Ahmed K, McHugh DA. Subthreshold micropulse diode laser photocoagulation for clinically significant diabetic macular oedema: a three-year follow up. Clin Exp Ophthalmol. 2007;35(7):640-644. doi:10.1111/j.1442-9071.2007.01566.x
  33. Kumar V, Ghosh B, Raina UK, Goel N. Subthreshold diode micropulse panretinal photocoagulation for proliferative diabetic retinopathy. Eye (Lond). 2009;23(11):2122-2123. doi:10.1038/eye.2008.416
  34. Luttrull JK, Sramek C, Palanker D, Spink CJ, Musch DC. Long-term safety, high-resolution imaging, and tissue temperature modeling of subvisible diode micropulse photocoagulation for retinovascular macular edema. Retina. 2012;32(2):375-386. doi:10.1097/IAE.0b013e3182206f6c
  35. Sivaprasad S, Dorin G. Subthreshold diode laser micropulse photocoagulation for the treatment of diabetic macular edema. Expert Rev Med Devices. 2012;9(2):189-197. doi:10.1586/erd.12.1
  36. Vujosevic S, Martini F, Convento E, et al. Subthreshold laser therapy for diabetic macular edema: metabolic and safety issues. Curr Med Chem. 2013;20(26):3267-3271. doi:10.2174/09298673113209990030
  37. Luttrull JK, Sinclair SH. Safety of transfoveal subthreshold diode micropulse laser for fovea-involving diabetic macular edema in eyes with good visual acuity. Retina. 2014;34(10):2010-2020. doi:10.1097/IAE.0000000000000177
  38. Parodi MB, Iacono P, Bandello F. Subthreshold grid laser versus intravitreal bevacizumab as second-line therapy for macular edema in branch retinal vein occlusion recurring after conventional grid laser treatment. Graefes Arch Clin Exp Ophthalmol. 2015;253(10):1647-1651. doi:10.1007/s00417-014-2845-6
  39. Lavinsky D, Cardillo JA, Melo LA Jr, Dare A, Farah ME, Belfort R Jr. Randomized clinical trial evaluating mETDRS versus normal or high-density micropulse photocoagulation for diabetic macular edema. Invest Ophthalmol Vis Sci. 2011;52(7):4314-4323. Published 2011 Jun 17. doi:10.1167/iovs.10-6828
  40. Lavinsky D, Palanker D. Nondamaging photothermal therapy for the retina: initial clinical experience with chronic central serous retinopathy. Retina. 2015;35(2):213-222. doi:10.1097/IAE.0000000000000340
  41. Lavinsky D, Sramek C, Wang J, et al. Subvisible retinal laser therapy: titration algorithm and tissue response. Retina. 2014;34(1):87-97. doi:10.1097/IAE.0b013e3182993edc
  42. Moutray T, Evans JR, Lois N, Armstrong DJ, Peto T, Azuara-Blanco A. Different lasers and techniques for proliferative diabetic retinopathy. Cochrane Database Syst Rev. 2018;3(3):CD012314. Published 2018 Mar 15. doi:10.1002/14651858.CD012314.pub2
  43. Chen G, Tzekov R, Li W, Jiang F, Mao S, Tong Y. Subthreshold micropulse diode laser versus conventional laser photocoagulation for diabetic macular edema: a meta-analysis of randomized controlled trials. Retina. 2016;36(11):2059-2065. doi:10.1097/IAE.0000000000001053
  44. Al-Barki A, Al-Hijji L, High R, et al. Comparison of short-pulse subthreshold (532 nm) and infrared micropulse (810 nm) macular laser for diabetic macular edema. Sci Rep. 2021;11(1):14. Published 2021 Jan 8. doi:10.1038/s41598-020-79699-9
  45. Sivaprasad S, Prevost AT, Vasconcelos JC, et al. Clinical efficacy of intravitreal aflibercept versus panretinal photocoagulation for best corrected visual acuity in patients with proliferative diabetic retinopathy at 52 weeks (CLARITY): a multicentre, single-blinded, randomised, controlled, phase 2b, non-inferiority trial. Lancet. 2017;389(10085):2193-2203. doi:10.1016/S0140-6736(17)31193-5
  46. Gross JG, Glassman AR, Liu D, et al. Five-year outcomes of panretinal photocoagulation vs intravitreous ranibizumab for proliferative diabetic retinopathy: a randomized clinical trial [published correction appears in JAMA Ophthalmol. 2019 Apr 1;137(4):467]. JAMA Ophthalmol. 2018;136(10):1138-1148. doi:10.1001/jamaophthalmol.2018.3255
  47. Writing Committee for the Diabetic Retinopathy Clinical Research Network, Gross JG, Glassman AR, et al. Panretinal photocoagulation vs intravitreous ranibizumab for proliferative diabetic retinopathy: a randomized clinical trial [published correction appears in JAMA. 2016 Mar 1;315(9):944] [published correction appears in JAMA. 2019 Mar 12;321(10):1008]. JAMA. 2015;314(20):2137-2146. doi:10.1001/jama.2015.15217
  48. Antoszyk AN, Glassman AR, Beaulieu WT, et al. Effect of intravitreous aflibercept vs vitrectomy with panretinal photocoagulation on visual acuity in patients with vitreous hemorrhage from proliferative diabetic retinopathy: a randomized clinical trial. JAMA. 2020;324(23):2383-2395. doi:10.1001/jama.2020.23027
  49. Brown DM, Ou WC, Wong TP, et al. Targeted Retinal photocoagulation for diabetic macular edema with peripheral retinal nonperfusion: three-year randomized DAVE trial. Ophthalmology. 2018;125(5):683-690. doi:10.1016/j.ophtha.2017.11.026
  50. Glassman AR. Results of a randomized clinical trial of aflibercept vs panretinal photocoagulation for proliferative diabetic retinopathy: is it time to retire your laser?. JAMA Ophthalmol. 2017;135(7):685-686. doi:10.1001/jamaophthalmol.2017.1652
  51. Obeid A, Gao X, Ali FS, et al. Loss to Follow-Up in Patients with Proliferative Diabetic Retinopathy after Panretinal Photocoagulation or Intravitreal Anti-VEGF Injections. Ophthalmology. 2018;125(9):1386-1392. doi:10.1016/j.ophtha.2018.02.034
  52. Writing Committee for the Diabetic Retinopathy Clinical Research Network, Fong DS, Strauber SF, et al. Comparison of the modified Early Treatment Diabetic Retinopathy Study and mild macular grid laser photocoagulation strategies for diabetic macular edema. Arch Ophthalmol. 2007;125(4):469-480. doi:10.1001/archopht.125.4.469
  53. Diabetic Retinopathy Clinical Research Network. The course of response to focal/grid photocoagulation for diabetic macular edema. Retina. 2009;29(10):1436-1443. doi:10.1097/IAE.0b013e3181bcef6b
  54. Baker CW, Glassman AR, Beaulieu WT, et al. Effect of Initial Management With Aflibercept vs Laser Photocoagulation vs Observation on Vision Loss Among Patients With Diabetic Macular Edema Involving the Center of the Macula and Good Visual Acuity: A Randomized Clinical Trial. JAMA. 2019;321(19):1880-1894. doi:10.1001/jama.2019.5790
  55. Beaulieu WT, Glassman AR, Baker CW, et al. Effect of initial aflibercept, laser, or observation on low-contrast visual acuity in eyes with diabetic macular edema and good vision: ancillary study within a randomized clinical trial. Transl Vis Sci Technol. 2021;10(3):3. doi:10.1167/tvst.10.3.3
  56. Brown DM. DAVE Trial (Diabetic Anti-VEGF): widefield guided panretinal photocoagulation for diabetic macular edema: eighteen-month results. Presented at: American Academy of Ophthalmology Annual Meeting Subspecialty Day; 2015; Las Vegas, NV.
  57. Suñer IJ, Peden MC, Hammer ME, Grizzard WS, Traynom J, Cousins SW. RaScaL: A Pilot Study to Assess the Efficacy, Durability, and Safety of a Single Intervention with Ranibizumab plus Peripheral Laser for Diabetic Macular Edema Associated with Peripheral Nonperfusion on Ultrawide-Field Fluorescein Angiography [published online ahead of print, 2014 Nov 26]. Ophthalmologica. 2014;doi:10.1159/000367902
  58. Berger A, Sheidow T, Cruess AF, Arbour JD, Courseau AS, de Takacsy F. Efficacy/safety of ranibizumab monotherapy or with laser versus laser monotherapy in DME. Can J Ophthalmol. 2015;50(3):209-216. doi:10.1016/j.jcjo.2014.12.014
  59. Chen G, Li W, Tzekov R, Jiang F, Mao S, Tong Y. Ranibizumab monotherapy or combined with laser versus laser monotherapy for diabetic macular edema: a meta-analysis of randomized controlled trials. PLoS One. 2014;9(12):e115797. Published 2014 Dec 26. doi:10.1371/journal.pone.0115797
  60. Ishibashi T, Li X, Koh A, et al. The REVEAL Study: Ranibizumab Monotherapy or Combined with Laser versus Laser Monotherapy in Asian Patients with Diabetic Macular Edema. Ophthalmology. 2015;122(7):1402-1415. doi:10.1016/j.ophtha.2015.02.006
  61. Mitchell P, Bandello F, Schmidt-Erfurth U, et al. The RESTORE study: ranibizumab monotherapy or combined with laser versus laser monotherapy for diabetic macular edema. Ophthalmology. 2011;118(4):615-625. doi:10.1016/j.ophtha.2011.01.031
  62. Figueira J, Fletcher E, Massin P, et al. Ranibizumab Plus Panretinal Photocoagulation versus Panretinal Photocoagulation Alone for High-Risk Proliferative Diabetic Retinopathy (PROTEUS Study). Ophthalmology. 2018;125(5):691-700. doi:10.1016/j.ophtha.2017.12.008
  63. Lang GE, Liakopoulos S, Vögeler J, et al. The RELATION study: efficacy and safety of ranibizumab combined with laser photocoagulation treatment versus laser monotherapy in NPDR and PDR patients with diabetic macular oedema. Acta Ophthalmol. 2018;96(3):e377-e385. doi:10.1111/aos.13574
  64. Tao Y, Jiang P, Zhao Y, et al. Retrospective study of aflibercept in combination therapy for high-risk proliferative diabetic retinopathy and diabetic maculopathy. Int Ophthalmol. 2021;41(6):2157-2165. doi:10.1007/s10792-021-01773-6
  65. Cho WB, Oh SB, Moon JW, Kim HC. Panretinal photocoagulation combined with intravitreal bevacizumab in high-risk proliferative diabetic retinopathy. Retina. 2009;29(4):516-522. doi:10.1097/IAE.0b013e31819a5fc2
  66. Filho JA, Messias A, Almeida FP, et al. Panretinal photocoagulation (PRP) versus PRP plus intravitreal ranibizumab for high-risk proliferative diabetic retinopathy. Acta Ophthalmol. 2011;89(7):e567-e572. doi:10.1111/j.1755-3768.2011.02184.x
  67. Lang GE, Stahl A, Voegeler J, et al. Observational outcomes in proliferative diabetic retinopathy patients following treatment with ranibizumab, panretinal laser photocoagulation or combination therapy - The non-interventional second year follow-up to the PRIDE study [published online ahead of print, 2021 Jun 14]. Acta Ophthalmol. 2021;10.1111/aos.14907. doi:10.1111/aos.14907
  68. Zhang W, Zhao G, Fan W, Zhao T. Panretinal photocoagulation after or prior to intravitreal conbercept injection for diabetic macular edema: a retrospective study [published correction appears in BMC Ophthalmol. 2021 May 10;21(1):205]. BMC Ophthalmol. 2021;21(1):160. Published 2021 Apr 1. doi:10.1186/s12886-021-01920-8
  69. Lu AQ, Todorich B. Combination antivascular endothelial growth factor and modified panretinal photocoagulation in management of proliferative diabetic retinopathy. J Vitreoret Dis. 2020;4(5):401-410.
  70. Barroso RMP, Messias K, Garcia DM, et al. ETDRS panretinal photocoagulation combined with intravitreal ranibizumab versus PASCAL panretinal photocoagulation with intravitreal ranibizumab versus intravitreal ranibizumab alone for the treatment of proliferative diabetic retinopathy. Arq Bras Oftalmol. 2020;83(6):526-534. doi:10.5935/0004-2749.20200096
  71. Yates WB, Mammo Z, Simunovic MP. Intravitreal anti-vascular endothelial growth factor versus panretinal LASER photocoagulation for proliferative diabetic retinopathy: a systematic review and meta-analysis [published online ahead of print, 2021 Feb 23]. Can J Ophthalmol. 2021;S0008-4182(21)00033-8. doi:10.1016/j.jcjo.2021.01.017
  72. Diabetic Retinopathy Clinical Research Network, Scott IU, Edwards AR, et al. A phase II randomized clinical trial of intravitreal bevacizumab for diabetic macular edema. Ophthalmology. 2007;114(10):1860-1867. doi:10.1016/j.ophtha.2007.05.062
  73. Sun JK, Glassman AR, Beaulieu WT, et al. Rationale and application of the Protocol S anti-vascular endothelial growth factor algorithm for proliferative diabetic retinopathy. Ophthalmology. 2019;126(1):87-95. doi:10.1016/j.ophtha.2018.08.001
  74. Mehta H, Gillies MC, Fraser-Bell S. Combination of vascular endothelial growth factor inhibitors and laser therapy for diabetic macular oedema: a review. Clin Exp Ophthalmol. 2016;44(4):335-339. doi:10.1111/ceo.12757
  75. Wells JA, Glassman AR, Ayala AR, et al. Aflibercept, Bevacizumab, or Ranibizumab for Diabetic Macular Edema: Two-Year Results from a Comparative Effectiveness Randomized Clinical Trial. Ophthalmology. 2016;123(6):1351-1359. doi:10.1016/j.ophtha.2016.02.022
  76. Bressler NM, Edwards AR, Beck RW, et al. Exploratory analysis of diabetic retinopathy progression through 3 years in a randomized clinical trial that compares intravitreal triamcinolone acetonide with focal/grid photocoagulation. Arch Ophthalmol. 2009;127(12):1566-1571. doi:10.1001/archophthalmol.2009.308
  77. Rittiphairoj T, Mir TA, Li T, Virgili G. Intravitreal steroids for macular edema in diabetes. Cochrane Database Syst Rev. 2020;11(11):CD005656. Published 2020 Nov 17. doi:10.1002/14651858.CD005656.pub3
  78. Nissen TPH, Vorum H, Aasbjerg K. Biologic Therapy and Treatment Options in Diabetic Retinopathy with Diabetic Macular Edema. Curr Drug Saf. 2021;16(1):17-31. doi:10.2174/1574886315666200902154322
  79. Diabetic Retinopathy Clinical Research Network, Googe J, Brucker AJ, et al. Randomized trial evaluating short-term effects of intravitreal ranibizumab or triamcinolone acetonide on macular edema after focal/grid laser for diabetic macular edema in eyes also receiving panretinal photocoagulation. Retina. 2011;31(6):1009-1027. doi:10.1097/IAE.0b013e318217d739
  80. Frizziero L, Calciati A, Torresin T, et al. Diabetic Macular Edema Treated with 577-nm Subthreshold Micropulse Laser: A Real-Life, Long-Term Study. J Pers Med. 2021;11(5):405. Published 2021 May 13. doi:10.3390/jpm11050405
  81. Abdelrahman A, Massoud W, Elshafei AMK, Genidy M, Abdallah RMA. Anatomical and functional outcomes of subthreshold micropulse laser versus intravitreal ranibizumab injection in treatment of diabetic macular edema. Int J Retina Vitreous. 2020;6(1):63. Published 2020 Dec 3. doi:10.1186/s40942-020-00265-6
  82. Lai FHP, Chan RPS, Lai ACH, et al. Comparison of two-year treatment outcomes between subthreshold micropulse (577 nm) laser and aflibercept for diabetic macular edema. Jpn J Ophthalmol. 2021;65(5):680-688. doi:10.1007/s10384-021-00846-4
  83. Passos RM, et al. Real-life outcomes of subthreshold laser therapy for diabetic macular edema. Int J Retina Vitreous. 2021;7(1):4.
  84. Schmidt-Erfurth U, Garcia-Arumi J, Bandello F, et al. Guidelines for the Management of Diabetic Macular Edema by the European Society of Retina Specialists (EURETINA). Ophthalmologica. 2017;237(4):185-222. doi:10.1159/000458539
  85. Regillo CD, Callanan DG, Do DV, et al. Use of Corticosteroids in the Treatment of Patients With Diabetic Macular Edema Who Have a Suboptimal Response to Anti-VEGF: Recommendations of an Expert Panel. Ophthalmic Surg Lasers Imaging Retina. 2017;48(4):291-301. doi:10.3928/23258160-20170329-03
  86. El Rami H, Barham R, Sun JK, Silva PS. Evidence-based treatment of diabetic retinopathy. Semin Ophthalmol. 2017;32(1):67-74. doi:10.1080/08820538.2016.1228397
  87. Wallsh JO, Gallemore RP. Anti-VEGF-resistant retinal diseases: a review of the latest treatment options. Cells. 2021;10(5):1049. Published 2021 Apr 29. doi:10.3390/cells10051049
  88. Yoshida S, Murakami T, Nozaki M, et al. Review of clinical studies and recommendation for a therapeutic flow chart for diabetic macular edema. Graefes Arch Clin Exp Ophthalmol. 2021;259(4):815-836. doi:10.1007/s00417-020-04936-w
  89. Kernt M, Cheuteu R, Liegl RG, et al. Navigierte fokale retinale Lasertherapie mit dem NAVILAS-System bei diabetischem Makulaödem [Navigated focal retinal laser therapy using the NAVILAS system for diabetic macula edema]. Ophthalmologe. 2012;109(7):692-698. doi:10.1007/s00347-012-2559-2
  90. Kozak I, Kim JS, Oster SF, Chhablani J, Freeman WR. Focal navigated laser photocoagulation in retinovascular disease: clinical results in initial case series. Retina. 2012;32(5):930-935. doi:10.1097/IAE.0b013e318227ab5b
  91. Kozak I, Oster SF, Cortes MA, et al. Clinical evaluation and treatment accuracy in diabetic macular edema using navigated laser photocoagulator NAVILAS. Ophthalmology. 2011;118(6):1119-1124. doi:10.1016/j.ophtha.2010.10.007
  92. Chhablani J, Mathai A, Rani P, Gupta V, Arevalo JF, Kozak I. Comparison of conventional pattern and novel navigated panretinal photocoagulation in proliferative diabetic retinopathy. Invest Ophthalmol Vis Sci. 2014;55(6):3432-3438. Published 2014 May 1. doi:10.1167/iovs.14-13936
  93. Azarcon CP, Artiaga JCM. Comparison of pain scores among patients undergoing conventional and novel panretinal photocoagulation for diabetic retinopathy: a systematic review. Clin Ophthalmol. 2021;15:953-971. Published 2021 Mar 2. doi:10.2147/OPTH.S294227
  94. Vergmann AS, Torp TL, Kawasaki R, et al. Retinal vascular oxygen saturation in response to a less extensive laser treatment in proliferative diabetic retinopathy [published online ahead of print, 2020 Dec 23]. Acta Ophthalmol. 2020;10.1111/aos.14727. doi:10.1111/aos.14727
  95. Barteselli G, Kozak I, El-Emam S, Chhablani J, Cortes MA, Freeman WR. 12-month results of the standardised combination therapy for diabetic macular oedema: intravitreal bevacizumab and navigated retinal photocoagulation. Br J Ophthalmol. 2014;98(8):1036-1041. doi:10.1136/bjophthalmol-2013-304488
  96. Liegl R, Langer J, Seidensticker F, et al. Comparative evaluation of combined navigated laser photocoagulation and intravitreal ranibizumab in the treatment of diabetic macular edema. PLoS One. 2014;9(12):e113981. Published 2014 Dec 26. doi:10.1371/journal.pone.0113981
  97. He X, Yuan Z, Gaeke S, et al. Laser-activated drug implant for controlled release to the posterior segment of the eye. ACS Applied Bio Materials. 2021;4(2):1461-1469. Doi:10.1021/acsabm.0c01334
  98. Hempel NJ, Merkl P, Asad S, et al. Utilizing laser activation of photothermal plasmonic nanoparticles to induce on-demand drug amorphization inside a tablet. Mol Pharm. 2021;18(6):2254-2262. doi:10.1021/acs.molpharmaceut.1c00077
