Drug delivery via the suprachoroidal space (SCS), with the potential to achieve chorioretinal concentrations 10 times greater than that of typical intravitreal injections,^1,2 has shown safety and efficacy in the treatment of uveitic macular edema with a proprietary formulation of triamcinolone acetonide, CLS-TA.³ Administration of CLS-TA in the SCS, combined with aflibercept, may also have the potential for reduced treatment burden over aflibercept monotherapy in diabetic macular edema.⁴ Although early efforts exploring SCS injections focused on steroid delivery, a wide range of additional agents and indications are currently under development.

TYROSINE KINASE INHIBITORS

Much of the conventional clinical treatment of retinal pathology hinges on the vascular endothelial growth factor (VEGF) cascade, with a particular focus on the blockade of VEGF-A. Although the class of anti-VEGF agents have revolutionized the treatment of diseases such as age-related macular degeneration (AMD), there is evidence to suggest that the blockade of VEGF-A upregulates the expression of VEGF-C⁵ and VEGF-D.⁶ This may blunt the overall response of treatment. In fact, a recent phase 2b trial demonstrated the benefit of broader inhibition: AMD patients receiving a combination of a VEGF-C and VEGF-D inhibitor along with a traditional VEGF-A inhibitor achieved superior visual acuity outcomes compared to those receiving anti-VEGF-A monotherapy.⁷

Whereas current agents block VEGF-A extracellularly, the class of tyrosine kinase inhibitors (TKIs) attack this same cascade by inhibiting the intracellular signaling of the VEGF receptors. One such TKI, axitinib, achieves broad blockade of the VEGF cascade by inhibiting VEGF receptors 1, 2, and 3. In vitro studies have shown axitinib to decrease retinal and choroidal neovascularization better than anti-VEGF-A or anti-PDGF-B, alone or in combination.⁸ Animal studies have established its ability to prevent neovascularization when applied topically in a murine ocular burn model, more effectively than equivalent doses of other TKIs.⁹ Axitinib also demonstrated decreased choroidal and retinal neovascularization when dosed systemically in rodents⁸ or in the SCS in pigs.¹⁰ A phase 1/2a trial of SCS-administered axitinib (CLS-AX; Clearside Biomedical) for the treatment of AMD is currently enrolling.¹¹

GENE THERAPY: VECTOR-BASED

There has been substantial interest in adeno-associated virus type 2 (AAV2) and type 8 (AAV8) vector gene therapy, for its therapeutic potential for indications ranging from AMD to diabetic macular edema (DME) and diabetic retinopathy (DR).^12-16 Much of the focus is on developing the delivery to optimize transduction and minimize inflammation, with approaches including surgical subretinal injection, intravitreal injection, and injection into the SCS.

The SCS route of administration holds the potential of fostering gene expression near the target tissues, while avoiding the potential inflammatory pitfalls that may occur with intravitreal treatment or the inherent surgical risks present with subretinal injections.

Animal models have established the feasibility of the SCS approach. An SCS injection of AAV8 vectors yielded expression of the transgene product in the photoreceptors and RPE of a significant portion of the eye, with a second injection further increasing the distribution of expression.¹⁷ More specifically, the suprachoroidal administration of RGX-314 (Regenxbio), an AAV8 vector with an anti-VEGF transgene product, resulted in significantly less vasodilation and vascular leakage than control eyes when challenged with VEGF165 injections.¹⁷ These SCS results in the rodent model were similar to the subretinal administration of the equivalent dose of RGX-314.¹⁷

Two phase 2 clinical trials for the SCS injection of RGX-314 (Figure 1) are currently enrolling, one for AMD and one for DR,^15,16 with the first cohort of AMD patients fully enrolled.¹⁸ As of December 31, 2020, SCS delivery of RGX-314 was noted to be generally well tolerated with no signs of inflammation.¹⁸

GENE THERAPY: DNA NANOPARTICLES

DNA nanoparticles (DNPs) represent a nonviral approach to gene therapy. They are composed of compacted single molecules of DNA with the ability to achieve similar gene expression compared to the AAV-vector based approach.¹⁹ Unlike traditional AAV vectors, DNPs offer the ability to deliver large genes,²⁰ as well as a potentially lower risk of immune-mediated inflammation.²¹ Animal models of retinitis pigmentosa have illustrated the possibility of efficacy, repeat delivery, and lack of toxicity of DNP technology.^22-25

Positive results were recently reported as to the tolerability and transfectability of DNPs delivered via the SCS in a rabbit model.²⁶ Similar rates of transfection of the RPE-choroid and retina were noted after either subretinal or SCS administration.²⁶ Given the encouraging preclinical data to date, further research is warranted.

VIRAL-LIKE PARTICLE BIOCONJUGATES

Although radiation therapy is highly effective and thus the gold standard for the treatment of choroidal melanomas, it is often associated with collateral damage and vision loss.²⁷ Given that injection into the SCS achieves drug delivery that is inherently compartmentalized in proximity to the choroid, its application may be of benefit in the search for alternative, vision-sparing treatment of choroidal tumors.

To that end, AU-011 (Aura Biosciences), a viral-like particle bioconjugate (VPB), is a first-in-class agent composed of viral nanoparticles derived from the human papillomavirus (HPV) and conjugated with infrared-activated particles, being developed for the treatment of choroidal melanoma.²⁸ Its capsids are derived from human papillomavirus to take advantage of this virus’s ability to preferentially bind to tumor cells.²⁹ Once AU-011 has targeted and bound to the tumor, it is activated with a near-infrared laser, leading to destruction of cell membranes and cell necrosis.

A phase 1b/2 open-label, ascending dose trial achieved a tumor control rate of 80% in phase 3 eligible subjects receiving 2 maximum-dose intravitreal treatments.³⁰ The rate of vision preservation, defined as a loss of 15 letters of visual acuity or less, was approximately 90%.

Although intravitreal treatment achieved high rates of tumor control and vision preservation, it was also associated with anterior chamber inflammation in close to 70%, vitreous inflammation in 85%, and increased intraocular pressure in approximately 40% of subjects.³⁰ Suprachoroidal space delivery of AU-011 would result in a more targeted administration of the drug, with possibly higher bioavailability at the tumor and less intraocular inflammation, potentially allowing for the treatment of a wider range of tumor sizes. The phase 2 trial exploring the delivery of AU-011 via the SCS has completed enrollment of its first 3 single-dose cohorts with a favorable safety profile to date, and is expected to complete enrollment early in 2021.³⁰

CONCLUSION

By way of its targeted and compartmentalized nature, injection via the SCS has the potential to maximize treatment effect and minimize exposure of other ocular tissues. SCS injection of CLS-TA has shown efficacy in the treatment of uveitic macular edema and the potential of addressing the treatment burden of DME. With strong continued interest in harnessing the benefits of SCS drug delivery, multiple agents, from TKIs, to vector-based and DNP-based gene therapy, to light-activated VPBs, are at different stages of development for a spectrum of indications. RP

REFERENCES

1. Patel SR, Lin AS, Edelhauser HF, Prausnitz MR. Suprachoroidal drug delivery to the back of the eye using hollow microneedles. Pharm Res. 2011;28(1):166-176. doi:10.1007/s11095-010-0271-y
2. Patel SR, Berezovsky DE, McCarey BE, Zarnitsyn V, Edelhauser HF, Prausnitz MR. Targeted administration into the suprachoroidal space using a microneedle for drug delivery to the posterior segment of the eye. Invest Ophthalmol Vis Sci. 2012;53(8):4433-4441. Published 2012 Jul 1. doi:10.1167/iovs.12-9872
3. Yeh S, Khurana RN, Shah M, et al. Efficacy and safety of suprachoroidal CLS-TA for macular edema secondary to noninfectious uveitis: phase 3 randomized trial. Ophthalmology. 2020;127(7):948-955. doi:10.1016/j.ophtha.2020.01.006
4. Barakat MR, Wykoff CC, Gonzalez V, et al. Suprachoroidal CLS-TA plus intravitreal aflibercept for diabetic macular edema: a randomized, double-masked, parallel-design, controlled study. Ophthalmol Retina. 2021;5(1):60-70. doi:10.1016/j.oret.2020.08.007
5. Cabral T, Lima LH, Mello LGM, et al. Bevacizumab injection in patients with neovascular age-related macular degeneration increases angiogenic biomarkers. Ophthalmol Retina. 2018;2(1):31-37. doi:10.1016/j.oret.2017.04.004
6. Lieu CH, Tran H, Jiang ZQ, et al. The association of alternate VEGF ligands with resistance to anti-VEGF therapy in metastatic colorectal cancer. PLoS One. 2013;8(10):e77117. Published 2013 Oct 15. doi:10.1371/journal.pone.0077117
7. Jackson T. OPT-302 phase 2b in wet AMD. A multicenter, randomized, double-masked, sham controlled study of intravitreal OPT-302 in combination with ranibizumab, in participants with wet AMD. Presented at: EURETINA; September 5, 2019; Paris, France.
8. Giddabasappa A, Lalwani K, Norberg R, et al. Axitinib inhibits retinal and choroidal neovascularization in in vitro and in vivo models. Exp Eye Res. 2016;145:373-379. doi:10.1016/j.exer.2016.02.010
9. Yuan X, Marcano DC, Shin CS, et al. Ocular drug delivery nanowafer with enhanced therapeutic efficacy. ACS Nano. 2015;9(2):1749-1758. doi:10.1021/nn506599f
10. Bhisitkul R, Kansara V, Ciulla TA. Suprachoroidal CLS-AX (axitinib injectable suspension) as a potential long-acting therapy for neovascular agerelated macular degeneration (nAMD). Presented at: American Academy of Ophthalmology virtual annual meeting; November 2020.
11. Clearside biomedical announces first patients enrolled in phase 1/2a clinical trial of CLS-AX (axitinib injectable suspension) for the treatment of wet AMD. Press release. 2021. https://ir.clearsidebio.com/news-releases/news-release-details/clearside-biomedical-announces-first-patients-enrolled-phase-12a
12. Pieramici D. Update on the subretinal RGX-314 gene therapy phase 1/2a study for the treatment of neovascular AMD. Presented at: American Academy of Ophthalmology virtual annual meeting; November 2020.
13. Wykoff CC. Intravitreal gene therapy for neovascular AMD with ADVM-022: results of the phase 2 OPTIC trial. Presented at: American Society of Retina Specialists virtual annual meeting; August 2020.
14. Adverum Biotechnologies completes patient enrollment for INFINITY phase 2 trial of ADVM-022 in DME and provides 2021 business outlook. Press release. 2021. https://investors.adverum.com/news-releases/news-release-details/adverum-biotechnologies-completes-patient-enrollment-infinity
15. Regenxbio announces dosing of first patient in phase II AAVIATE trial of RGX-314 for the treatment of wet AMD using suprachoroidal delivery. Press release. September 9 2020. http://ir.regenxbio.com/news-releases/news-release-details/regenxbio-announces-dosing-first-patient-phase-ii-aaviatetm
16. Regenxbio announces dosing of first patient in phase II ALTITUDE trial of RGX-314 for the treatment of diabetic retinopathy using suprachoroidal delivery. Press release. 2020. https://regenxbio.com/press_release/regenxbio-announces-dosing-of-first-patient-in-phase-ii-altitude-trial-of-rgx-314-for-the-treatment-of-diabetic-retinopathy-using-suprachoroidal-delivery-2/
17. Ding K, Shen J, Hafiz Z, et al. Widespread ocular transgene expression after aav8-vectored suprachoroidal gene transfer. Paper presented at: Association for Research in Vision and Ophthalmology; 2019; Vancouver, Canada.
18. Regenxbio announces update on RGX-314 and pivotal program for the treatment of wet amd and new gene therapy program for the treatment of duchenne muscular dystrophy. Press release. January 5, 2021. http://ir.regenxbio.com/news-releases/news-release-details/regenxbio-announces-update-rgx-314-and-pivotal-program-treatment
19. Han Z, Conley SM, Makkia R, Guo J, Cooper MJ, Naash MI. Comparative analysis of DNA nanoparticles and AAVs for ocular gene delivery. PLoS One. 2012;7(12):e52189. doi:10.1371/journal.pone.0052189
20. Fink TL, Klepcyk PJ, Oette SM, et al. Plasmid size up to 20 kbp does not limit effective in vivo lung gene transfer using compacted DNA nanoparticles. Gene Ther. 2006;13(13):1048-1051. doi:10.1038/sj.gt.3302761
21. Adijanto J, Naash MI. Nanoparticle-based technologies for retinal gene therapy. Eur J Pharm Biopharm. 2015;95(Pt B):353-367. doi:10.1016/j.ejpb.2014.12.028
22. Cai X, Nash Z, Conley SM, Fliesler SJ, Cooper MJ, Naash MI. A partial structural and functional rescue of a retinitis pigmentosa model with compacted DNA nanoparticles. PLoS One. 2009;4(4):e5290. doi:10.1371/journal.pone.0005290
23. Cai X, Conley SM, Nash Z, Fliesler SJ, Cooper MJ, Naash MI. Gene delivery to mitotic and postmitotic photoreceptors via compacted DNA nanoparticles results in improved phenotype in a mouse model of retinitis pigmentosa. FASEB J. 2010;24(4):1178-1191. doi:10.1096/fj.09-139147
24. Koirala A, Makkia RS, Cooper MJ, Naash MI. Nanoparticle-mediated gene transfer specific to retinal pigment epithelial cells. Biomaterials. 2011;32(35):9483-9493. doi:10.1016/j.biomaterials.2011.08.062
25. Han Z, Koirala A, Makkia R, Cooper MJ, Naash MI. Direct gene transfer with compacted DNA nanoparticles in retinal pigment epithelial cells: expression, repeat delivery and lack of toxicity. Nanomedicine (Lond). 2012;7(4):521-539. doi:10.2217/nnm.11.158
26. Kansara VS, Cooper M, Sesenoglu-Laird O, Muya L, Moen R, Ciulla TA. Suprachoroidally delivered DNA nanoparticles transfect retina and retinal pigment epithelium/choroid in rabbits. Transl Vis Sci Technol. 2020;9(13):21. doi:10.1167/tvst.9.13.21
27. Aziz HA, Singh N, Bena J, Wilkinson A, Singh AD. Vision Loss Following Episcleral Brachytherapy for Uveal Melanoma: Development of a Vision Prognostication Tool. JAMA Ophthalmol. 2016;134(6):615-620. doi:10.1001/jamaophthalmol.2016.0104
28. Light-activated AU-011. Accessed February 7, 2021. http://www.aurabiosciences.com/clinical-programs/
29. Kines RC, Cerio RJ, Roberts JN, et al. Human papillomavirus capsids preferentially bind and infect tumor cells. Int J Cancer. 2016;138(4):901-911. doi:10.1002/ijc.29823
30. Shields C, Bhavsar AR, Capone A, et al. AU-011, a targeted therapy for primary treatment of choroidal melanoma (CM) via intravitreal (IVT) or surachoroidal (SC) administration. Presented at: American Academy of Ophthalmology virtual annual meeting; 2020.
